Max Volume, Large-Format UV LED
Flatbed Inkjet Printer
DMPS 9575 LED UV Printers
Max Volume Production *Industry best in class
X-axis motion for up to 950mm
Gantry moving type
Best Stability in Printing Quality
Bulk Ink System™ *Industry best in class
Unlike single-use cartridges, this system allows for
100% utilization of available ink.
Auto cleaning and capping System
Programmable and automatic cleaning capping
UV print head anti-cure system
DMPS printer is designed to diminish the curing of ink in print head nozzles when printing on reflective surfaces
Inline printing
white, colors and clear print head simultaneously, inline in a single pass.
Laser automatic head height adjustment
Laser sensors automatically adjust head height to reduce print head strikes.
Suction system
Hold substrates firmly when printing
Varnish Ink
The optional varnish ink can give partial laminating or over coating effect on whatever area is
3-demensional substrate is available
Flat-bed can be adjustable up to 150mm in height.
Division |
Specifcation |
Print head |
DOD piezo print head |
Max. Print size |
950mm x 750mm (37in x 29in) |
Max. resolution |
Up to 1200 x 1200 dpi |
Print speed |
13.5sqm(135 sqf)/h for 4pass, 12 sqm(120 sqf)/h for 6pass, 6 sqm(60 sqf)/h for 12pass |
Head Clearance |
150mm (5.9in) |
Proudct size / Weight |
(W)1960mm x (L)1450mm x (H)1350mm / 375kg (77in x 57in x H:53in / 827lb) |
Input power |
120/220V AC, 10A |
Operation system |
Window 2000 / XP / vista / 7 |
Application software |
Bundle Rip (ONYX RIP Optional) |
|
DMPS 9575 LED UV Printer
- Print directly onto wood, acrylic, PVC, aluminum, ABS, polycarbonate, glass, crystal, stainless steel,
ceramic tile, electrical components, CDs, DVDs and much more
- UV-protect print head design and capping station to ensure consistent, reliable printing
- Vanish ink can give partial laminating & over coating effect on whatever area is
- Brilliant white ink option – prints onto even the darkest substrates
- Clear overcoat ink option to seal your images for added durability
- Precision image placement and pass-to-pass registration
- Ink droplet size from 7 to 21 picoliter
- Bundled with ICC-profiled custom RIP
